Description

Model number: Kubota D1703-M

Displacement: 0.435 gal/1.647 L

Rated output power/speed: 18.5 KW/2200 rpm

Max. torque: 97.4 N.m/1500 rpm



Max. travel speed: 22 mph / 1.3 mph / 3.6 km/h / 2.2 km/h

Swing speed: 9.5 rpm

Max. grade ability: 30°

Bucket digging force: 27.6 KN

Bucket arm digging force: 20.4 KN

Maximum tractive force: 31.6 KN



Pump type: Piston pump

Operating pressure: 3190 psi / 22 Mpa

Hydraulic oil tank capacity: 13.2 gal / 50 L

Flow rate: 26.1 gal / 99 L/min

Engine oil capacity: 1.8 gal / 7 L

Fuel tank capacity: 15.8 gal / 60 L



Boom swing (left): 71°

Boom swing (right): 52°

Grounding resistance: 31.6 KPa

Track material: Steel (rubber is optional)

Track tensioning device type: Grease cylinder
